Hyundai Ioniq (AE): Your vehicle at a glance / Plug-in Hybrid Vehicle Exterior Overview
â– Front view
1. Hood
2. Windows
3. Sunroof
4. Wiper blade
5. Tires and wheels
6. Headlamp
7. Outer side view mirror
8. Daytime running light (DRL)
9. Charging door
â– Rear view
1. Door lock
2. Fuel filler door
3. Antenna
4. Rear combination lamp
5. High mounted stop lamp
6. Liftgate
7. Rear view monitor
8. Parking Distance Warning system (Reverse)
9. Towing hook
1. Engine oil filler cap 2. Engine oil dipstick 3. Engine coolant cap 4. Engine coolant reservoir 5. Inverter coolant reservoir 6. Brake fluid reservoir 7.
1. Door lock/unlock button 2. Driver position memory system 3. Side view mirror control switch 4. Central door lock switch 5. Power window switches 6.
Other information:
Hyundai Ioniq (AE) 2017-2022 Service & Repair Manual: General safety information and caution
Safety PrecautionPrecautions To Take Before Servicing High Voltage System • Since hybrid vehicles contain a high voltage battery, if the high voltage system or vehicles are handled incorrectly, this might lead to a serious accidents like electric shock and electric leakage.
Hyundai Ioniq (AE) 2017-2022 Service & Repair Manual: Parking Distance Warning (PDW) Sensor. Repair procedures
Removal1.Disconnect the negative (-) battery terminal.2.Remove the front / rear bumper cover.(Refer to Body - "Front Bumper Cover")(Refer to Body - "Rear Bumper Cover")3.Disconnect the connector (A) from the parking assist sensor.4.Remove the sensor (A) by pulling out both ends of the sensor holder.
