Hyundai Ioniq (AE): Hybrid Control System / DC Fuse. Schematic diagrams
| Component Location |
Component Location1. DC Fuse2. Inverter Connector [↔ Power Relay Assembly (PRA)]3. Inverter Connector [↔ Electric A/C compressor]
Removal • Be sure to read and follow the "General Safety Information and Caution" before doing any work related with the high voltage system.
