Hyundai Ioniq (AE) 2017-2022 Service & Repair Manual / Body (Interior and Exterior) / Hood / Hood Latch Release Handle. Components and components location

Component Location

1. Hood latch release handle

❮Hood Weatherstrip. Repair procedures

Replacement1.Remove the hood weatherstrip (A). • Be careful not to scratch the hood weatherstrip. 2.To install, reverse the removal procedure.

Hood Latch Release Handle. Repair procedures❯

Replacement1.Using a socket (B), remove the hood release handle (A).2.To install, reverse the removal procedure. • Make sure the hood latch cable is connected properly.
