Hyundai Ioniq (AE): Hood / Hood Weatherstrip. Repair procedures
| Replacement |
| 1. | Remove the hood weatherstrip (A).
|
| 2. | To install, reverse the removal procedure. |
Replacement1.Using a clip remover, remove the clips and then the hood insulator pad (A). • Be careful not to scratch the hood panel.
Component Location1. Hood latch release handle
