Hyundai Ioniq (AE): Crankcase Emission Control System / Positive Crankcase Ventilation (PCV) Valve. Description and operation
| Operation Principle |
Inspection1. After disconnecting the vapor hose from the PCV valve, remove the PCV valve. 2. Reconnect the PCV valve to the vapor hose.3. Run the engine at idle, then put a finger over the open end of the PCV valve and make sure that intake manifold vacuum can be felt.
Removal1. Disconnect the vapor hose (A).2. Remove the PCV valve (B).Inspection1.Insert a thin stick (A) into the PCV valve (B) from the threaded side to check that the plunger movement.
