Hyundai Ioniq (AE): Windshield Wiper/Washer / Rain Sensor. Components and components location

Components and Components Location

    InspectionFront Washer Motor1.With the washer motor connected to the reservoir tank, fill the reservoir tank with water.    â€¢ Before filling the reservoir tank with water, check the filter for foreign material or contamination.

    Circuit Diagram

    Other information:

    Hyundai Ioniq (AE) 2017-2022 Service & Repair Manual: Evaporator Core. Repair procedures

    Replacement1.Disconnect the negative (-) battery terminal. 2.Remove the heater and blower assembly.(Refer to Heater - "Heater Unit") 3.Remove the evaporator core cover (A) after loosening the mounting screws.4.Pull out the evaporator temperature sensor (A) from the evaporator core.

    Hyundai Ioniq (AE) 2017-2022 Service & Repair Manual: Intake Actuator. Repair procedures

    Inspection1.Turn the ignition switch OFF.2.Disconnect the intake actuator connector.3.Verify that the intake actuator operates to the fresh position when connecting 12V to terminal 3 and grounding terminal 4.Verify that the intake actuator operates to the recirculation position when connected in reverse.
