Hyundai Ioniq (AE): Lighting System / Rheostat. Components and components location
| Components |
Inspection1.The SJB can be diagnosed by using the GDS. The SJB communicates with the GDS which then displays inputs and outputs along with codes. It will be able to diagnose defects of hazard lamp switch with GDS quickly.
Inspection1.Disconnect the negative (-) battery terminal.2.Remove the crash pad lower panel.(Refer to Body - "Crash Pad Lower Panel")3.Disconnect the rheostat switch connector (A).
