Hyundai Ioniq (AE): Active Air Flap (AAF) / Schematic diagrams
| Schematic Diagram |
| Circuit Diagram |
Components1. Air duct2. Flap3. Housing4. Actuator assembly
Removal and installation • Check for foreign objects caught in the flap and linkage area.1.Disconnect the battery negative terminal.
