Hyundai Ioniq: Rear Seat / Rear Seat Back Cover. Components and components location
Hyundai Ioniq (AE) 2017-2025 Service Manual / Body (Interior and Exterior) / Rear Seat / Rear Seat Back Cover. Components and components location
| Component Location |
| 1. Rear seat back cover [LH] | 2. Rear seat back cover [RH] |
Rear Seat Assembly. Repair procedures
Replacement[Rear seat cushion assembly]1.Loosen the mounting bolts, remove the rear seat cushion assembly (A).2.Disconnect the rear seat cushion extension connector (A)...
Rear Seat Back Cover. Repair procedures
Replacement[LH]
•
Put on gloves to prevent hand injuries.
•
When removing with a flat-tip screwdriver or remover, wrap protective tape around the tools to prevent damage to components...
